BF39605-39612

Specifications

1、 Poles;2  to6

2、 Current rating:8.0A AC/DC

3、Voltage  rating:250V  AC/DC

4、  Temperature range:-25°C to+85°C

5、Contact resistance: ≤15mΩ

6、Insulation   resistance:≥1000MΩ

7、 Withstand      voltage:1500V       AC/minute

8、 Applicable   wire:AWG#20to#16

9、  Material:

Housing:Nylon66  UL94 V-0

Terminal:Phos.Bronze Tin-Plated
