PM-1.27-1 nPL-H=4.6-PC=2.8 ffc/fpc connector factory

1.27mm,0.35×0.15SQ Female
Header, H=2.0.Dual Row,
Straight SMT
Current Rating: 1.0AMP
Insulation Resistance:≥1000MΩ
Contact Resistance:≤0.02Ω
Withstanding Voltage 50Ov, AC,DC
Operation Temperalure:-40℃~105℃
Contact: copper Alloy
Plating: Au or Sn over Ni
Insulator: High Temperature Thermoplastic(UL94V-O)
